General Product Information
| Dimension Length | 0.752 |
| Dimension Height | 0.340 |
| Dimension Width | 0.310 |
| Connection Inlet Flange | DN 63 ISO-K |
| Noise / Sound Level | 63.00 db(A) |
| Power Supply Frequency |
50 Hz
60 Hz |
| Weight | 130.00 |
| Power Supply Phase | 3-Ph |
| Cooling Method | Air Cooling |
| Connection vacuum outlet flange | DN 63 ISO-K |
| Power Supply Voltage |
3Ph 200/230/400 50 Hz
3Ph 200-208/265/460 60 Hz |
| IP Rating | IP20 |
| Leak Rate | 1.000 × 10⁻⁵ |
| Dimension Comments | The dimensions length, width and height try to describe the outer shape of this particular product in its typical orientation when standing on the ground. We always recommend checking the detailed dimensions given in 2D drawings in the instruction manual or the 3D shapes given in 3D models. |
| Connection Inlet / Outlet Flange | DN 63 ISO-K | DN 63 ISO-K |
Performance Data
| Power Total Rated | 2200.00 |
| Power Total Rated @50Hz | 2200.00 |
| Power Total Rated @60Hz | 2400.00 |
Environmental Conditions
| Temperature Ambient Operation Max | 40.00 |
| Temperature Ambient Operation Min | 12.00 |
Classification
| Classification High / Medium / Rough Vacuum pump | Rough Vacuum Pump |
| Classification Dry or Wet Pump | Dry |
| Classification Vacuum Pump Technology | Mechanical Booster Pump |
| Classification Product Pressure Range |
Medium Vacuum: 1 mbar - 1·10⁻³ mbar
Rough Vacuum: 1000 mbar - 1 mbar |
