VARODRY VD 160 HD/O2 - 50Hz 200/400V Purge
EUR 23,887.00
General Product Information
| Dimension Length | 1.06 |
| Dimension Height | 0.428 |
| Dimension Width | 0.599 |
| Connection Inlet Flange | 2" BSPT (Rc) Female |
| Noise / Sound Level |
70.00
db(A)
70.00 db(A) |
| Power Supply Frequency |
50 Hz
60 Hz |
| Weight | 130.00 |
| Power Supply Phase | 3-Ph |
| Cooling Method | Air Cooling (forced - fan) |
| Connection vacuum outlet flange | 1 1/2" BSPP (G) Female |
| IP Rating | IP55 |
| Dimension Comments | The dimensions length, width and height try to describe the outer shape of this particular product in its typical orientation when standing on the ground. We always recommend checking the detailed dimensions given in 2D drawings in the instruction manual or the 3D shapes given in 3D models. |
| Connection Inlet / Outlet Flange | 2" BSPT (Rc) Female | 1 1/2" BSPP (G) Female |
Environmental Conditions
| Temperature Ambient Operation Min | 0.000 |
| Temperature Ambient Storage Min | -20.00 |
| Temperature Ambient Storage Max | 60.00 |
Classification
| Classification High / Medium / Rough Vacuum pump | Rough Vacuum Pump |
| Classification Dry or Wet Pump | Dry |
| Classification Vacuum Pump Technology | Dry Screw Pump |
| Classification Product Pressure Range |
Medium Vacuum: 1 mbar - 1·10⁻³ mbar
Rough Vacuum: 1000 mbar - 1 mbar |
Performance Data
| Power Total Rated | 3000.00 |
